SA-H80 Koryak – Medium utility helicopter

1. Turn on power – BAT1 – 2
2. Turn on avionics key
3. Turn on flight computer – ADIRS
4. Disable rotor brake
5. Unlock fuel valves – ENG – 1 – 2
6. Turn on engine fuel pumps – 1 – 2
7. Turn on lights as required – Position – Beacon – Strobe
8. Enable hydraulic systems – HYD A – B – C
9. Turn on engine main – ENG 1 – 2 MAIN
10. Enable generators – GEN 1 – 2 BUS
11. When you are ready to takeoff switch engine modes – ENG 1 – 2 IDLE/FLIGHT

Notes: -[If ambient temperature below 0°C] – Enable Anti Ice – PROBE – ENGINES – REAR / MAIN ROTOR -Aircraft is balanced for no ordnance, full fuel tank – different configurations might require slight trim adjustments -On the overhead panel you can set the rotor rpm 2400-4200, default 3300 this will change the characteristics of the aircraft depending as you need – fuel efficiency, speed, MTOW..

---

The aircraft is equipped with our advanced 4th gen avionics system "ANTARES" A total of 10 screens configurable on 2 touchscreens

1. Touchscreen map with waypoint controls – "+" and "-" is used for zoom, "R" will reset position on the map, Waypoint selection controls are described in autopilot controls
2. Horizontal situation indicator
3. Engine information – ENG 1 – 2
4. Fuel & Hydraulics information
5. Enabled electrical systems information
6. Onboard RADAR
7. Weapon selection system
8. Utility screen for hardpoints (modules to be added)
9. Tail camera
10. Winch camera

---

This aircraft is equipped with an advanced autopilot system, it’s 4 parts can be enabled seperately.

• Altitude hold
• Heading hold
• Cruise mode
• Waypoint autopilot

For altitude and heading hold Set your target altitude/heading on the middle dashboard monitor and enable the respective switch Cruise mode Cruise mode will simply engage forward thrust and hold current heading and altitude until it’s disabled For waypoint autopilot You need to have a waypoint or more on the map in order to use this properly. There are 3 buttons in the right upper corner on the map screen (1) labeled "C","L" and "A". Button "A" will add a wapoint to the position you have selected on the map. "L" will delete your last waypoint and "C" will clear all waypoints.

---

There are two configurable pylons. Each can be armed on the middle dashboard and ordnance status can be seen on the MFD[7] "Ordnance GPS" is used to set target coordinates for GPS guided ordnance The default configuration contains: -TGP1A camera targeting pod -3x Aim16 all round radar guided missiles You can equip the plane with any weapon from this pack Weapon manager has been prepared for 2nd generation of smart weapons that will be released

Crew – 2 pilots Length – 18.75m* Height – 5.75m Width – 5.25* Empty weight – 5053kg MTOW – 23300kg** Max fuel – 10200L Fuel grade – Jet A1 Engine unit -2x Skytech JT7 Unit power – 3250hp / 2423kW** Top speed – 198kts** Range at top speed – 456NM/845km** *Excluding rotor **@3300 rotor RPM
