Electrical grids update
This item presents the global update of all previous mods with switchgears and substations.
!!! Vanilla power lines 6MW and 14MW have wrong wire numbering, so they connects incorrectly. We are waiting for a fix from 3division. Also, mirrored buildings will not work correctly.
- Thanks to the new game mechanics, all wires are connected automatically. Auxiliary and duplicate objects have been removed.
- All objects are easily compatible with each other and are universal in themselves.
- Towers can be placed on any terrain.
- Optimization is increased significantly.
- A large number of minor edits and visual improvements.
- Objects are still adapted to a certain number of power line circuits, and when connecting a line and an object with a different number of circuits, the wires may be connected incorrectly, which, however, will not affect the game functions of the object.
- All objects from previous mods can be replaced and unsubscribed, they are no longer relevant. (old mods remain available in the workshop).
- Downlead 20kV, single-circuit
- Downlead 20kV, double-circuit
- Tapping from a single-circuit 20kV power line
- Tapping a circuit from a double-circuit 20kV power line
- Splitter for double-circuit 20kV power line
- Downlead 110kV, single-circuit
- Downlead 110kV, double-circuit
- Tapping from a single-circuit 110kV power line
- Tapping from a double-circuit 110kV power line
- Splitter for double-circuit 110kV power line
- Splitter for quadruple-circuit 110kV power line
- Substation 110kV with single-circuit air input (4.6 and 10 MW)
- Substation 110kV with double-circuit air input (any power)
- Substation 110kV with one cable input
- Substation 110kV with two cable inputs
[/list]
Downleads – in this case, connections of overhead and cable power lines.Tapping – branch of a power line by connecting wires to a main power line and taking power from it. The 110 kV taps were recreated according to the project 3.407-94.Splitter – the division of a multi-circuit transmission line into separate lines with a smaller number of circuits (in this case, 1×2=2×1 or 1×4=2+1+1), the power of one transmission line is distributed over two/three others.Substation – open main step-down substation 110/20 kV, typical project 407-3-191. A dead-end facility in which high voltage is converted to medium voltage. Medium voltage outputs are adapted both for any overhead line and cable line (a lot of outputs to choose). A large substation with air input has one connection for a double-circuit overhead line and two more for single-circuit ones (also optional).
Transformer TDN10000/110Disconnector RND3-2-110/630-1000Disconnector RLND-1-10Separator OD3-110M/630-1000Short circuiter K3-110MValve arrester RVS-110Grounding reactor ZROM-300/10Reactor’s transformer TM-250/6-10Auxiliary transformer ТМ-63/6-10Portals UO-110-L2/3Supports A10-1, US110-7, US110-8, UO-110
Model, textures, code, debugging – Shotkey
[boosty.to]
Revisions:
Old revisions of this mod are available below. Click the link to download.
